Features
- Exclusive Driver Unit for STAX Earspeakers
- 4-Input Selector for Multiple Source Connectivity
- High-Performance Power Amplifier Design
- Optimized for STAX Electrostatic Earspeakers
STAX SRM-T8000 Driver unit for Earspeakers
STAX SRM-T8000 Driver unit for Earspeakers
Also available on demo in store
Special Order Item
Available To Order
Available To Order
Free Delivery 1 - 3 DaysFree Delivery 1 - 3 Days
2-year-warranty
Trade in productTrade in product
Book a Demonstration
Available to collect immediatelyAvailable to collect immediatelyPrice range: £4,395 through £5,295
Specifications
| Frequency response | 1Hz – 115kHz +0, -3dB |
| Rated input level | 100mV (at 100V output) |
| Maximum input level | 30Vrms. (at minimum volume) |
| Gain | 60dB (x 1000) |
| Harmonic distortion | 0.01% or less (1kHz) |
| Input impedance | 50kΩ (RCA input), 50kΩx 2 (XLR input) |
| Maximum output voltage | 470Vrms (1330Vp-p) / 1kHz |
| Bias voltage | 580V DC |
| Mains voltage | AC120V/AC220/AC230/AC240, 50/60Hz (depending on your country’s voltage) |
| Power consumption | 95W/Max. 58W (without optional slot) |
| Operating temperature | 0 to 35 degrees C (less than 90% humidity, non-condensing) |
| Dimension | 320 (W) x103 (H) x395 (D) mm (maximum protruding portion included) |
| Weight | 7.3kg |
| Others | equipped with PARALLEL OUT, optional slot and volume by-pass function and mute function. |
Description
SRM-T8000 Driver unit for Earspeakers
• The SRM-T8000 is an exclusive driver unit (power amplifier) with a 4-input selector developed in order to ideally drive STAX electrostatic earspeakers.
• The unit incorporates a high-quality double-axis 4-gang volume controller along with XLR connectors that can connect to all kinds of analogue line-level output terminals.
• The hybrid amplifier configuration with a strictly selected low-noise 6922 dual triode tube for the first stage and high-current emitter-follower at the output stage brings out the maximum performance of earspeakers. Its natural uncoloured sound has been realized by eliminating the coupling capacitor that affects the sound
• The balanced amplifier configuration with a low-noise dual-triode tube eliminated the transformer or inverting amplifier after the XLR balanced input terminal.
• Non-magnetic chassis construction is employed, and only the carefully selected electronic components free from aged deterioration are used taking both their sonic quality and performance into consideration.
• The SRM-T8000 is equipped with “direct mode” function, enabling it to connect to a preamplifier output terminal or to use your favourite Also, two RCA inputs and XLR balanced input can bypass the incorporated volume controller (Line 4 input does not have this function).
• Optional extension slot (LINE4) is provided for future use. Refer to the instruction manual of this optional card.
• The foot rubber of the SRM-T8000 features fire-resistant ultra-hard high-grip type and vibration-proof properties. So the unit hardly slides when placed on a table etc. Please lift it when you move it.
Additional information
| Colour | Black, Silver |
|---|
Warranty
Backed with a 2-year Stax warranty
